| Image Senso | 1/3" Progressive Scan CMOS sensor |
| Day & Night | ICR type |
| Focal Length | 4mm |
| Aperture | F1.6 |
| FOV | Horizontal FOV: 82.3°, Vertical FOV: 44.7°, Diagonal FOV: 97.4° |
| Supplementary Light | Two High-Power Spotlights and Infrared Lights |
| Supplementary Light Distance | Up to 30 m/100 ft (depending on environment) |
| IR Wavelength | 850nm |
| Night Vision Mode | Smart Mode, Full Color Mode, Black & White Mode |
| Video Encoding Format | H.265, H.264 |
| Main Stream Resolution | 2304 ×1296, 1920 × 1080, 1280 × 720 |
| Sub Stream Resolution | 640 × 360, 352 × 288 |
| Frame Rate | 1-30fps, Default 20fps |
| Bit Rate | 512kbps -- 4096kbps |
| Bit Rate Control | CBR,VBR |
| Audio Encoding Format | G.711A, G.711U, AAC |
| Audio Sampling Rate | 8 kHz |
| Audio Communication | Two-way Audio, Voice Input |
| Image Enhancement | DWDR, BLC, HLC, 3D DNR |
| Privacy Mask | 4 Areas |
| Ethernet Port | 1 RJ45, 10Mbps/100Mbps auto-negotiation Ethernet port |
| ONVIF | Support |
| Protocols | TCP/IP, UDP, ICMP, HTTP, HTTPS, DHCP, DNS, DDNS, RTP, RTSP, RTCP, NTP,
ARP, WebSockets |
| Web Browser | Plug-in free live view: Chrome, Edge, Opera |
| Pan Movement Range | 0°-355° |
| Tilt Movement Range | 0°-90° |
| Preset | 6 |
| Patrol | Panoramic Patrol, Preset Patrol |
| Antenna | Internal antenna |
| Wireless Standard | IEEE 802.11 b/g/n/ax |
| Transmission Rate | Up to 287Mbps |
| Channel Width | 20/40 MHz |
| Modulation | DSSS/OFDM/OFDMA |
| Frequency Band | 2.4GHz: 2412MHz-2472MHz(CH1-CH13) |
| Transmit Power | 2.4GHz: < 0.1W(EIRP) |
| Security | 64/128-bit WEP, WPA/WPA2, WPA-PSK/WPA2-PSK, WPA3 |
| Smart Detection | Motion detection, Human detection, Vehicle detection |
| Smart Linkage | Sound&light Alert, Human Tracking |
| DIY Audio | 3 Customized Audios |
| Audio Input | Built-in MIC |
| Audio Output | Built-in Speaker |
| Storage | Built-in Micro SD Card Slot, Up to 512 GB |
| Reset Button | Support |
| LED Indicator | Dual Color(red & blue) LED Indicator |
| Power | 12V DC,1A,Ø5.5mm&Ø2.1mm Power Plug |
| Material | Plastic |
| Product Dimension | 120mm x 120mm x 146mm(4.7" ×4.7" × 5.7") |
| Package Dimension | 167mm x 131mm x 251mm(6.5" ×5.1" × 9.9") |
| Product Weight | 367g(0.81lb) |
| With Package Weight | 860g(1.89lb) |
| Protection Level | IP65 |
| Installation Method | Wall Mounting, Ceiling Mounting, Pole Mounting |
| Certification | CE, RoHS, FCC, RCM, UKCA |
| Temperature | Operating Temperature: -30°C ~ 60°C (-22°F ~ 140°F)
Storage Temperature: -40°C ~ 70°C (-40°F ~ 158°F) |
| Humidity | Operating Humidity: 10% ~ 95% RH (non-condensing)
Storage Humidity: 3% ~ 95% RH (non-condensing) |
| Package Contents | Camera
Power Adapter (cord length: 3m)
Installation Template
Mounting Bracket
Mounting Accessories Kit
Waterproof Kit
Quick Installation Guide |
